The AVMatrix SC1115 is a down converter which allows for the conversion of SDI digital signals to DVI, decoding the digital audio and converting it to analog stereo.


  • 1 x 3G-SDI input, 1 x DVI output, 1 x 3G-SDI pass through output.
  • SDI input auto detection and configuration
  • DVI output supports down scaling and frame rate conversion
  • DVI output formats can be controlled via rotary DIP switches
  • De-embed 3G-SDI audio to external analog stereo audio
  • LED indicators for clear 3G-SDI operation
  • 5-12V wide voltage



Analog Audio Output
Connector 3.5mm Earphone Audio Slot
Digital Sampling 48K
Impedance 600 ohm
Output Signal Analog Stereo Audio
DVI Output
Connector DVI-I
DVI Format 800 x 600 @ 60 Hz to 1600 x 1200 @ 60Hz
Impedance 100 ohms
Output Signal VESA Standard DVI Signal
Signal Amplitude 800mV +- 10% (75 ohm)
SDI Input / Output
Connector BNC Compliant to IEC 169-8 standards
Impedance 75 ohm
Signal Amplitude 800mV +- 10% (75 ohm)
Bit Rate 270Mbps ~ 2.97Gbps
Common Parameters
Dimension 112 x 120 x 30mm
Operating Voltage DC 5-12V
Power <2W
Storage Humidity (%RH) 0% - 90% RH
Storage Temperature (°c) -20°c to 75°c
Weight (g) 300g
Working Humidity (%RH) 20% - 70% RH
Working Temperature (°c) 0°c to 50°c
Analog Audio Output
Connector 3.5mm Earphone Audio Slot
Digital Sampling 48K
Impedance 600 ohm
Output Signal Analog Stereo Audio
DVI Output
Connector (DVI) DVI-I
DVI Format 800 x 600 @ 60 Hz to 1600 x 1200 @ 60Hz
Impedance (DVI) 100 ohms
Output Signal (DVI) VESA Standard DVI Signal
Signal Amplitude (DVI) 800mV +- 10% (75 ohm)
SDI Input / Output
BNC Connector BNC Compliant to IEC 169-8 standards
Signal Impedance 75 ohm
Bit Rate 270Mbps ~ 2.97Gbps
SDI Signal Amplitude 800mV +- 10% (75 ohm)
Common Parameters
Dimension 112 x 120 x 30mm
Operating Voltage DC 5-12V
Power <2W
Storage Humidity (%RH) 0% - 90% RH
Storage Temperature (°c) -20°c to 75°c
Weight (g) 300g
Working Humidity (%RH) 20% - 70% RH
Working Temperature (°c) 0°c to 50°c

AVMatrix SC1115 - 3G-SDI to DVI Converter

  • Brand: AVMatrix
  • Product Code: AVMatrix SC1115 - 3G-SDI to DVI Converter
  • Availability: Pre-Order
  • 291.22€
