The perfect unit for live events and shows. Featuring 2 IPS panels and 3G SDI connectivity and mountable in a 3U rack system or events managers board.

PLEASE NOTE - BEFORE ORDERING


PLEASE CHECK THAT YOUR CAMERA'S OUTPUT FEED FREQUENCY IS COMPATIBLE WITH THE INPUT FREQUENCIES OF THIS MONITOR BY CLICKING HERE FOR OUR LIST OF MONITORS AND SUPPORTED FREQUENCIES TYPES (FOR BLACKMAGIC CAMERA OWNERS AND OTHER 25FPS CAMERA TYPES)

black magic pocket cinema camera compatible

Black Magic Pocket Cinema Camera Compatible

This monitor is fitted with the 2674 processing chip - which gives a greater range of input frequencies that can be used. For the full range of compatible frequencies please click here

7 inch high definition screen

Twin 7” IPS monitors with widescreen aspect

The Lilliput RM7028/S has 2 ultra high resolution, widescreen IPS type LCD panels which can accept 2 independent high definition video signals for maximum functionality in a live event situation

High resolution LCD

IPS screen gives 720p native resolution

The RM7028/S features IPS screen panels with a native resolution of 1280x800 pixels. This high resolution gives an extremely detailed image potentially avoiding problems in the post-production environment making it an ideal choice for the discerning professional user.

High contrast LCD

800:1 Contrast ratio

The RM7028/S features an ultra high 800:1 contrast ratio giving accurate colour representation and crisp picture quality.

High brightness LCD

High brightness LCD panel

The RM7028/S is sunlight readable with a brightness ratio of 400 cd/m2 making it ideal for all situations

dslr optimised

DSLR optimised system

The Lilliput RM7028/S is designed around compatibility with professional multimedia and video equipment.

multiple input types

Multiple input connections available

The RM7028/S comes with connectivity for 3G SDI, HDMI, Component (YPbPr) and composite and with 2 independent screens this allows for great flexibility when running your event




entertainment solutions

Entertainment and multimedia solutions.

Lilliputs rack mounted monitors are ideal for installing into sound stages and recording studios.

agriculture solutions

Industrial and Agricultural solutions.

Lilliput rack mounted monitors can be installed into existing 19" rack systems for monitoring and control in the industrial environment.

photography solutions

Photography solutions.

Lilliputs rack mounted monitors are optimised for use with professional grade video and photography equipment.

vehicle solutions

Vehicular solutions.

Lilliput rack mount monitors can be installed in outside broadcast vehicles for monitoring and image control.

Lilliput RM7028 Instruction Manual Download
Lilliput RM7028 Mechanical Drawing Download
Monitor Specification
Screen Size (diagonal) 2 x 7" LED IPS Screen
Aspect Ratio 16:9
Native Resolution 1280x800 (Native)
Maximum Resolution up to 1920 x 1080
Viewing Angle (degrees) 178/178
Brightness Ratio (cd/m2) 400
Contrast Ratio 800:1
Video Inputs 2 x 3G-SDI, 2 x HDMI, 2 x YPbPr, 2 x Composite, 2 x Tally Connection, 1 x USB Mini
Video Outputs 2 x 3G-SDI, 2 x HDMI, 2 x YPbPr, 2 x Composite
Input Power 12V DC
Operating Temperature -20 - 60
Contents Of Box
Product RM-7028 monitor
Power Adaptor 12V 2A Power Adaptor (UK,EU,US)
Dimensions
Height (mm) 133.5
Width (mm) 482.5
Depth (mm) 25.3
Weight (g) 2885

There are no reviews for this product.

Write a review

Please login or register to review

Lilliput RM-7028/S - 3U 3G-SDI Dual Rackmount Monitors

  • Brand: Lilliput
  • Product Code: RM-7028S
  • EAN: 6950821600948
  • Availability: In Stock
  • 525.00€
