The Lilliput 663/O/P2 monitor is a 7” widescreen  LCD field monitor with HDMI, YPbPr (via BNC) and Composite Video input.  DSLR optimised, and featuring a sturdy metal bezel, peaking and focus assist functions and collapsible sunhood. Supplied in an attractive flight case for added security.

Version 2 units have the latest firmware and features including waveform analysis and audio meters


PLEASE NOTE - BEFORE ORDERING


PLEASE CHECK THAT YOUR CAMERA'S OUTPUT FEED FREQUENCY IS COMPATIBLE WITH THE INPUT FREQUENCIES OF THIS MONITOR BY CLICKING HERE FOR OUR LIST OF MONITORS AND SUPPORTED FREQUENCIES TYPES (FOR BLACKMAGIC CAMERA OWNERS AND OTHER 25FPS CAMERA TYPES)

black magic pocket cinema camera compatible

Black Magic Pocket Cinema Camera Compatible

This monitor is fitted with the 2674 processing chip - which gives a greater range of input frequencies that can be used. For the full range of compatible frequencies please click here


7 inch high definition screen

7” Monitor with Widescreen

Lilliput's 663-O/P2 is a versatile 7" monitor. The high resolution 7" LCD displays bright, clear images in a small sturdy form factor. An ideal monitor for the adventurous photographer.

pro video market

DSLR Compatible Monitor

The 663-O/P2 is one of our most versatile monitors to date, offering the user a much increased viewing area when compared to the cameras native internal viewfinder. Combined with the functionality of the built in focus assist and peaking tools, thie 663-O/P2 is the ideal tool for users trying to get the most out of their DSLR cameras.

hdmi output

Advanced Functionality

To get the best of pin-sharp pictures, the 663-O/P2 has a raft of refinement applications preloaded into the monitor to help. It features fully specced Waveforms, Peaking, Histograms, False Colour, and Pixel to Pixel modes that will help turn your good shots into GREAT shots.

High resolution LCD

IPS Screen = 720p Native Resolution

The 663-O/P2 features a native 1280 x 800 panel, with intelligent upscaling when receiving higher resolution HDMI signals - meaning that you can display 1920 x 1080p resolution imagery on a super small screen. This high resolution gives an extremely detailed image - opening options in the post-production environment, and making it an ideal choice for the discerning professional user.

High contrast LCD

800:1 Contrast Ratio

The 663-O/P2 features an ultra high 800:1 contrast ratio as a facet of its advanced design. As a result, the onscreen image is a highly accurate rendition of the video - helping to avoid issues of colour continuity in post-production.

Programmable Function Control

For added practicality, the 663-O/P2 also supports 4 user programmable functionbuttons. If you use a feature regularly, instead of hunting through menus you can assign them to a specific button on the face of the monitor - increasing the effectiveness of your workflow.

HDMI output

HDMI Passthrough Included.

Most DSLR cameras feature only a single HDMI output, meaning need to link to more than one output you'd need a splitter. The 663-O/P2 further eases this problem as it can be daisy-chained to anopther monitor to build a video array - or indeed connect to any other HDMI monitor.

High brightness monitor

Variable Input Power Tolerance

The 663-O/P2 has been designed to accept a wide range of input voltages - from 6V to 24V. This allows for connection to a multitude of power sources, giving greater flexibility when used in outdoor environments.

viewing angle

High viewable angles for all round visibility

Following on from our earlier models which featured improved viewing angles, the LCD panel on the 663 was enhanced still further, allowing the image to be viewed by a large production crew simultaneously.

Internal battery

Extended choice of battery plates

With the 663, two battery plates are bundled, from a selection including a DU21, QM91D, and F970. When purchasing please select your requirement on the website or call for advice. V-type and A-N battery plates are also available - please enquire for pricing.

Please note: Returns on this product will not be accepted by Lilliput UK Ltd with respect to incompatibility problems.

HDMI, component and composite

Features HDMI,  component and composite inputs

Most DSLR cameras now feature HDMI output, but larger production cameras output high definition via component signal.  Additionally, the 663 is also available with an HD-SDI video input ( 663/O/P/S)

Hot shoe mount adapter

A Shoe Mount adapter is supplied with this monitor

By having the adapter included, the customer can avoid facing additional cost of purchasing a separate unit

The 663 features 2  1/4" BS Whitworth thread inserts, allowing  the monitor to be quickly mounted on either a tripod or camera.


photography solutions

Photography and Video solutions.

Lilliput HDMI monitors are designed for optimal use with DSLR camera and video rigs.

entertainment solutions

Entertainment and multimedia.

Lilliput monitors are ideal for small form factor multimedia systems such as karaoke systems, DJ setups and as confidence monitors for home cinema systems.

Lilliput 663 Instruction ManualDownload
Lilliput 663 CE CertificateDownload
Lilliput 663 LCD Panel DatasheetDownload
Monitor Specification
Screen Size (diagonal) 7 Inch
Aspect Ratio 16:9
Native Resolution 1280x800 (native)
Maximum Resolution up to 1920x1080
Viewing Angle (degrees) 178º x, 178º y
Brightness Ratio (cd/m2) 400
Contrast Ratio 800:1
Backlight LED
Video Inputs HDMI, YPbPr (via BNC), Composite
Video Outputs HDMI
Audio Outputs Built in Speaker, 3.5mm Audio line out
Input Power DC 12V (XLR Connector)
Operating Temperature -20ºC to 60ºC
Mounting Options ¼ inch BSW thread, shoe mount

There are no reviews for this product.

Write a review

Please login or register to review

Lilliput 663/O/P2 - 7" HDMI field monitor

  • Brand: Lilliput
  • Product Code: 663/O/P2
  • EAN: 6950821600788
  • Availability: In Stock
  • 314.99€
